Foxeer M10Q 250 GPS Module with QMC5883L Compass
₹2,850.00
The Foxeer M10Q 250 GPS is a high-performance GNSS positioning module designed specifically for FPV drones, long-range UAVs, and autonomous flight controllers.
It combines the u-blox M10 series chipset with a QMC5883L digital compass, delivering fast satellite lock, high positioning accuracy, and stable navigation data even in challenging environments.
With support for multiple GNSS constellations (GPS, GLONASS, Galileo, BeiDou), the M10Q offers faster cold starts and better signal reliability compared to older M8-based GPS modules, making it an excellent upgrade for modern flight controllers.
Quantity
⭐ Key Features
✔ u-blox M10 GNSS Chipset
Next-generation receiver with improved sensitivity, faster lock time, and higher accuracy.
✔ Multi-Constellation Support
Simultaneous tracking of GPS + GLONASS + Galileo + BeiDou for superior global coverage.
✔ Integrated QMC5883L Compass
Reliable digital magnetometer for precise heading and yaw information.
✔ 250mm Cable for Flexible Mounting
Ideal for mounting GPS away from power noise sources.
✔ Compact & Lightweight Design
Perfect for FPV quads, long-range wings, cinewhoops, and mapping drones.
✔ Wide FC Compatibility
Works seamlessly with Betaflight, INAV, ArduPilot, PX4.
📌 Technical Specifications
| Specification | Details |
|---|---|
| Model | Foxeer M10Q 250 |
| GNSS Chipset | u-blox M10 |
| Compass | QMC5883L |
| Supported GNSS | GPS, GLONASS, Galileo, BeiDou |
| Update Rate | Up to 10 Hz |
| Operating Voltage | 3.3V–5V |
| Cable Length | 250 mm |
| Connector | JST-GH 6-pin |
| Dimensions | ~18 × 18 mm |
| Weight | ~5 g |
🔧 Compatibility & Recommended Use
Flight Controllers
-
Pixhawk 2.4.8 / 4 / 6C
-
Cube Orange / Cube Orange+
-
Matek F405 / F722 / H743
-
SpeedyBee F405 / F7
-
Holybro Durandal
Firmware Support
-
ArduPilot
-
PX4
-
INAV
-
Betaflight (GPS rescue & telemetry)
🛠 Typical Applications
✓ GPS Rescue (FPV)
✓ Return-to-Home (RTH)
✓ Waypoint Missions
✓ Long-Range FPV
✓ Mapping & Survey Drones
✓ Fixed-Wing UAVs
📦 Package Contents
-
1× Foxeer M10Q GPS Module
